If you have followed the steps for configuring EAP and are encountering problems, there are only a few things that go wrong. This article goes through the most common issues and how to fix them.
Server unresponsive after sending request
Problem: A lot of text scrolls by, the server sends an Access-Challenge, and then prints out a message saying
Cleaning up request ...
After that, nothing more happens. The debug output will likely contain a message about unknown CA.
Diagnosis: The client does not like the server certificate, or the CA which issued that certificate.
Solution: On a testing system, un-check Validate Server Certificate as noted in the EAP page.
Solution: On a production system, ensure that the client has been configured with the certificates from the proper Certificate Authority and Server certificate, as noted in the EAP page.
Solution: On a production system, ensure that the client has Server certificate has the proper “TLS Web server” OID’s (Object Identifiers). (Yes, EAP needs a “web server” certificate. That decision was made 20 years ago, and can’t be changed now.)
Don’t worry, the FreeRADIUS certificate creation scripts in /etc/raddb/certs/ create the certificates with the proper information. Unless you already have a certificate management system, these certificate creation scripts should always be used to create RADIUS certificates.
See also KB-814394. Note that we do not necessarily agree with their explanations, but the fix does appear to work.
Server sends Access-Reject
Problem: The server sends an Access-Reject.
Diagnosis: The password entered on the client does not match the “known good” password that the server has.
Solution: Double-check that the passwords are the same. Use the simplest possible configuration to do this.
Other issues
Problem: The Windows client still won’t connect.
Diagnosis: If none of the above fixes work, and you still see the Access-Challenge sent… and then nothing, the problem is some kind of Windows magic.
Solution: Enable EAPHost Tracing.
To enable tracing, run the following commands from a privileged command prompt (i.e. as Administrator):
netsh wlan set tra yes netsh ras set tr * en
After the problem has been reproduces (using one login attempt), tracing can be disabled by:
netsh ras set tr * dis netsh wlan set tra no
The output files (*.etl) will be in the %2Ewindir%2E\tracing\wireless\ directory, usually in various subdirectories. The .etl files can be converted to .txt files via the following command:
tracerpt
The final files can put put on a web page, and questions posted to the freeradius-users list.
